Digital Sampling Oscilloscopes
SD203TM-26(7M)
SD203TM-26(7M) is a digital sampling oscilloscope for UWB measurement and radar instrumentation workflows. Bandwidth, channel, and triggering characteristics remain preserved in the technical specification section.
Maximal Sampling Rate 7000 kHz
Bandwidth Of Channel (0÷26) GHz
Input Impedance 50 Ohm
Number Of Channels 2
Technical Specification
Technical Specification
| Number of Channels | 2 |
|---|---|
| Data exchange | through LPT1 or LPT2 ports in EPP mode or USB |
| Operation mode | Oscilloscope mode |
| Maximal Sampling Rate | 7000 kHz |
| Bandwidth of channel | (0÷26) GHz |
| Input impedance | 50 Ohm |
| DC offset range | -1000÷1000(adjustable with step 1 mV) |
| Sensitivity Range | 1÷200 mV/div (adjustable with step 1 mV/div) |
| Dynamic range | ±1000 mV |
| Noise factor (RMS) | 1.6 mV |
| Number of averaging | 4096(adjustable) |
| Accuracy of amplitude measurements | (Ux /1000mV+40mV/Ux) % |
| Zero Drift of Y-axis | ± 0.3 mV |
| Time Base | (0.002 ÷ 6) ns/div @ Sampling Rate 7 MHz (0.002 ÷ 8.2) ns/div@ Sampling Rate 6 MHz(0.002 ÷; 9.4) ns/div@ Sampling Rate 5 MHz(adjustable with step 0.002 ns/div) |
| Fine Delay | 0 ÷ 4 ns (adjustment range) 0.01 ns (step) |
| Coarse Delay: | Adjustment range (step 4 ns):0 ÷ 60 ns @ Sampling Rate 7 MHz0 ÷ 82 ns @ Sampling Rate 6 MHz0 ÷ 94 ns @ Sampling Rate 5 MHz |
| Number of samples in time window | 4 ÷ 4096(adjustable) |
| Short-time triggering instability (Jitter) in TDR Modewith test Pulse Generator Head | 8.0 ps (2.0 ps RMS) @ Fine Delay 0÷1 ns |
| Accuracy of time measurements | 3ps +2%Tx (5ps/div<Scale<100 ps/div) 5ps +0,1%Tx (100ps/div<Scale<1 ns/div)5ps +0,1%Tx(100ps/div<Scale<1 ns/div)10ps +0,1%Tx(Scale>1 ns/div) |
| RF connectors | SMA |
| System time drift | < 15 ps/hour(with Generator) |
| Spectrum stability | 1÷2% (@ 26 GHz)(with Pulse Generator Head GZ1117DN25) |
| Temperature range | (+5÷ +35) °C |
| Power Supply | AC main (90÷260) V;(50÷ 60)Hz |
